技术参数SPECIFICATIONS
口适用线规(Applicablewires):AWG24#~16#
温度范围(Temperaturerange):-25℃~85℃
额定电压(Voltagerating):300V.Ac/Dc
额定电流(Currentrating):12A max
接触电阻(Contactresistance):≤0.01Ω
绝缘电阻(Insulationresistance):≥1000MΩ
耐压(Withstandvoltage):2000VAc/1min
材料(Material):
壳体(Housing):尼龙(PA66)UL94V-2(0)
端子(Terminal):磷青铜(PhosbronzeTin/plated)
黄铜(BrassTin/plated)
